Prism

Category :
Prism
Browse number : ...
Release time : 2026-03-16

Detailed Description

High-Precision Transform Prism / Light Wave

Engineered specifically for micro-optical systems, including medical endoscopes and precision industrial inspection probes, ensuring exceptional tolerance control and optical stability.

Technical Specifications

Parameter	Specification	Note
Outer Diameter	Φ 2.8 (-0.02 / -0.04) mm	Precision fit tolerance
Inner Diameter	Φ 0.6 (+0.05 / 0) mm	Center aperture structure
Thickness	0.6 ± 0.01 mm	High-precision path control
Surface Accuracy	R = ∞ (Plano)	Double-sided polished
Tolerance Grade	s7	Industrial standard

Product Highlights

Ultra-Miniature Design: Optimized for optical modules under Φ3mm.
Light Path Control: Specialized "Light Wave" structure reduces stray light and enhances contrast.
Material Flexibility: Available in H-K9L, Fused Silica, or Sapphire upon request.
Coating Services: Custom AR (Anti-Reflective) or metal reflective coatings available.
