Cylindrical Plano & Plano-Convex Micro Lenses for Medical Imaging
| Size (Φ x L mm) | Material Options |
|---|---|
| Φ0.73 x 1.0 to Φ2.0 x 19.4 | UVFS / H-K50 |
| Φ2.8 x 19.4 to Φ6.53 x 42 | H-QK3 / H-BAK7 |
Providing ultra-small diameters starting from Φ0.7mm with high-refractive index materials.
| Dimension (Φ x L) | Radius (R) | Material | Performance Specs |
|---|---|---|---|
| Φ0.7 x 1.65 mm | R 0.524 | JGS1 (Fused Silica) | • Surface: 40/20 ~ 20/10 • Accuracy: 1/8λ ~ 1/4λ • Centration: < 3' ~ 5' |
| Φ1.25 x 6.0 mm | R 1.856 | JGS1 | |
| Φ2.8 x 6.0 mm | R 3.5 | H-LAF10L (High Index) |
