High-durability Sapphire ($Al_2O_3$) windows designed to protect objective lenses from harsh medical sterilization environments and physical impact. Available in flat and angled ($\theta$) configurations.
| Diameter ($\Phi$) Range | Thickness (T) | Angle ($\theta$) |
|---|---|---|
| Φ 0.7 mm to Φ 9.0 mm | 0.3 mm - 2.5 mm | 0°, 12°, 30°, 45° |
Integrated multi-element objective assemblies for high-resolution micro-imaging.
| System Diameter (ΦA) | Aperture (ΦB) | Radius (R1/R2) |
|---|---|---|
| Φ 0.56 mm to Φ 0.64 mm | 0.08 mm - 0.18 mm | Micro-series |
| Φ 1.23 mm to Φ 1.75 mm | 0.235 mm - 0.28 mm | Standard series |
