High-precision achromatic doublet and micro-lens assemblies designed for medical endoscopy and micro-imaging applications, featuring advanced bonding technology and tight geometric tolerances.
| Feature | Specification Range | Design Details |
|---|---|---|
| Standard Doublet | Length: 6.16 ± 0.02 mm Dia: Φ 2.8 (-0.02 / -0.04) |
Curvature: R 3.342 |
| Precision Micro Lens | Length: 6.5 ± 0.06 mm Dia: Φ 1.8 (+0.024 / +0.014) |
s7 Tolerance Class |
| Micro-Thin Lens | Thickness: 0.6 ± 0.03 mm Dia: Φ 2.8 ± 0.02 |
Center Thk: 0.3 ± 0.01 mm |
Rigid Endoscopes, Video Probes, Optical Fiber Couplers, and Micro-Imaging Sensors for Industrial/Medical Inspection.
